LD39080DT12-R
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LD39080 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 150mV 6.5mm 800mA -40C~125C
PDF
/
Inventory: 9945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.28mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LD39080
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Outputs 1
Voltage - Input (Max) 6V
Output Voltage 1.2V
Output Type Fixed
Max Output Current 800mA
Output Configuration Positive
Quiescent Current 2.5mA
Control Features Enable
Accuracy 1.5 %
Output Voltage 1 1.22V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature, Short Circuit
Voltage Dropout (Max) 0.3V @ 800mA
Reference Voltage 1.22V
Dropout Voltage 150mV
Dropout Voltage1-Nom 0.15V
Min Output Voltage 1.22V
Voltage Tolerance-Max 3%
Input Bias Current 1mA
Output Voltage Accuracy 1.5 %
Dimensions
Length 6.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
