LD2980ABM50TR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LD2980 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 120mV 1.3mm 50mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.67496
≥100 USD $0.634304
≥500 USD $0.517616
≥1000 USD $0.480797
≥3000 USD $0.4092
Inventory: 20112
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 1.75mm
Length 3mm
Height 1.3mm
Technical
Output Voltage Accuracy 0.5 %
Input Bias Current 80μA
Dropout Voltage1-Nom 0.12V
Dropout Voltage 120mV
PSRR 63dB (1kHz)
Voltage Dropout (Max) 0.225V @ 50mA
Current - Quiescent (Iq) 150μA
Protection Features Over Current, Over Temperature
Min Input Voltage 2.5V
Number of Regulators 1
Output Voltage 1 5V
Accuracy 0.5 %
Control Features Enable
Quiescent Current 100μA
Output Configuration Positive
Max Output Current 50mA
Output Type Fixed
Output Voltage 5V
Voltage - Input (Max) 16V
Number of Outputs 1
Current - Supply (Max) 1.2mA
Pin Count 5
Base Part Number LD2980
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance 0.5%
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 14 Weeks
