LD29300D2M80R
RoHS
/
Package D2PAK
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Positive GULL WING BIPOLAR EAR99 voltage regulator linear 125C 3A 700mV
PDF
/
Inventory: 9081
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case D2PAK
Number of Pins 4
Technical
Packaging Tape & Reel
JESD-609 Code e0
Pbfree Code no
Number of Terminations 3
ECCN Code EAR99
Terminal Finish TIN LEAD
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Number of Functions 1
Pin Count 3
JESD-30 Code R-PSSO-G3
Number of Outputs 1
Output Type Fixed
Max Output Current 3A
Polarity Positive
Current - Output 3A
Quiescent Current 50mA
Accuracy 1 %
Voltage - Output 8V
Output Voltage 1 8V
Min Input Voltage 2.5V
Current - Input Bias 20mA
Max Input Voltage 30V
Dropout Voltage 700mV
Dropout Voltage1-Nom 0.4V
Voltage Tolerance-Max 2%
Load Regulation-Max(%) 0.08%
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
