LD1117DTTR
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LD1117 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 1.1V 2.4mm 1.3A 12W
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.5016
≥1 USD $0.5016
≥10 USD $0.44176
≥100 USD $0.415008
≥500 USD $0.338712
≥1000 USD $0.314653
≥3000 USD $0.267784
Inventory: 9179
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Power Dissipation 12W
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.28mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LD1117
Pin Count 3
Number of Outputs 1
Output Voltage 15V
Output Type Adjustable
Max Output Current 1.3A
Max Supply Voltage 15V
Output Configuration Positive
Power Dissipation 12W
Current - Output 800mA
Quiescent Current 10mA
Accuracy 1 %
Max Output Voltage 15V
Number of Regulators 1
Protection Features Over Current, Over Temperature
Voltage Dropout (Max) 1.2V @ 800mA
PSRR 75dB (120Hz)
Reference Voltage 1.262V
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C
Dropout Voltage 1.1V
Dropout Voltage1-Nom 1.1V
Min Output Voltage 1.25V
Input Bias Current 5mA
Output Voltage Accuracy 1 %
Load Regulation-Max(%) 0.4%
Physical
Weight 4.535924g
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
Dimensions
Height 2.4mm
Length 6.6mm
Width 6.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
