LD1086D2T12
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LD1086 Tube Surface Mount Over Current Over Temperature voltage regulator linear 1.3V 4.83mm 1.5A -40C~125C
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.736606
≥1 USD $0.736606
≥10 USD $0.694912
≥100 USD $0.655578
≥500 USD $0.618474
≥1000 USD $0.583463
Inventory: 1590
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code not_compliant
Base Part Number LD1086
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 30V
Output Voltage 12V
Output Type Fixed
Output Configuration Positive
Current - Output 1.5A
Output Voltage 1 12V
Number of Regulators 1
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 10mA
Voltage Dropout (Max) 1.5V @ 1.5A
PSRR 71dB (120Hz)
Dropout Voltage 1.3V
Dropout Voltage1-Nom 1.3V
Voltage Tolerance-Max 2%
Input Voltage Absolute-Max 30V
Input Bias Current 5mA
Dimensions
Height Seated (Max) 4.83mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
