LD1085V33
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LD1085 Tube Through Hole Over Current Over Temperature voltage regulator linear 1.3V 2.54mm 3A -40C~125C
PDF
/
Buying Options
Total Price: USD $5.83
Unit Price: USD $5.8311
≥1 USD $5.8311
≥10 USD $4.7842
≥100 USD $4.63505
≥500 USD $4.4859
≥1000 USD $4.3358
Inventory: 1594
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Output Voltage Accuracy 1 %
Input Bias Current 5mA
Input Voltage Absolute-Max 30V
Voltage Tolerance-Max 2%
Dropout Voltage1-Nom 1.3V
Dropout Voltage 1.3V
PSRR 72dB (120Hz)
Voltage Dropout (Max) 1.5V @ 3A
Protection Features Over Current, Over Temperature
Number of Regulators 1
Input Voltage (Min) 4.9V
Output Voltage 1 3.3V
Quiescent Current 10mA
Current - Output 3A
Output Configuration Positive
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 30V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSFM-T3
Pin Count 3
Base Part Number LD1085
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
