L79L15ACUTR
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
L79L15 Tape & Reel (TR) Surface Mount Over Temperature Short Circuit voltage regulator linear 1.7V 1.6mm 100mA 0C~125C
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.4928
≥1 USD $0.4928
≥10 USD $0.42152
≥100 USD $0.393536
≥500 USD $0.314776
≥1000 USD $0.292336
≥3000 USD $0.24735
Inventory: 4640
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2.6mm
Length 4.6mm
Height 1.6mm
Technical
Output Voltage Accuracy 5 %
Voltage Tolerance-Max 5%
Dropout Voltage 1.7V
PSRR 39dB (120Hz)
Current - Quiescent (Iq) 6mA
Protection Features Over Temperature, Short Circuit
Min Input Voltage -23V
Number of Regulators 1
Output Voltage 1 15V
Accuracy 5 %
Quiescent Current 6.5mA
Output Configuration Negative
Max Output Current 100mA
Output Type Fixed
Output Voltage -15V
Voltage - Input (Max) -35V
Number of Outputs 1
Pin Count 3
Base Part Number L79L15
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C
Physical
Number of Pins 3
Package / Case TO-243AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
Factory Lead Time 15 Weeks
