L79L05ABD
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
L79L05 Tube Surface Mount Over Temperature Short Circuit voltage regulator linear 1.7V 4.9mm 100mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.3458
≥1 USD $0.3458
≥10 USD $0.28405
≥100 USD $0.2755
≥500 USD $0.266
≥1000 USD $0.25745
Inventory: 1994
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Dropout Voltage1-Nom 1.7V
Dropout Voltage 1.7V
PSRR 49dB (120Hz)
Current - Quiescent (Iq) 5.5mA
Protection Features Over Temperature, Short Circuit
Min Input Voltage -10V
Number of Regulators 1
Output Voltage 1 5V
Max Output Voltage -5V
Output Configuration Negative
Min Supply Voltage -7V
Max Supply Voltage -20V
Voltage -5V
Max Output Current 100mA
Output Type Fixed
Output Voltage -5V
Voltage - Input (Max) -30V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 6mA
Pin Count 8
Base Part Number L79L05
Time@Peak Reflow Temperature-Max (s) 30
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
