L78S75CV-DG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
L78S75 Tube Through Hole Over Current Over Temperature Short Circuit voltage regulator linear 35V 2A 0C~150C
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $1.06744
≥100 USD $0.990704
≥500 USD $0.969848
≥1000 USD $0.948886
≥3000 USD $0.92796
Inventory: 514
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Technical
Operating Temperature 0°C~150°C
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Technology BIPOLAR
Number of Functions 1
Base Part Number L78S75
Pin Count 3
Voltage - Input (Max) 35V
Output Voltage 7.5V
Output Type Fixed
Max Output Current 2A
Output Configuration Positive
Quiescent Current 8mA
Output Voltage 1 7.5V
Number of Regulators 1
Min Input Voltage 35V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 8mA
PSRR 48dB (120Hz)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
