L78M09ABV image
Favorite
L78M09ABV image
Favorite
RoHS
RoHS RoHS compliant
Package TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description L78M09 Tube Through Hole Over Current Over Temperature Short Circuit voltage regulator linear 2V 2.54mm 500mA -40C~125C
PDF
/
Inventory: 5568
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3

Technical

Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number L78M09
Pin Count 3
JESD-30 Code R-XSFM-T3
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 9V
Output Type Fixed
Output Configuration Positive
Current - Output 500mA
Quiescent Current 6mA
Output Voltage 1 9V
Voltage - Output (Min/Fixed) 9V
Number of Regulators 1
Min Input Voltage 35V
Protection Features Over Current, Over Temperature, Short Circuit
PSRR 56dB (120Hz)
Dropout Voltage 2V
Dropout Voltage1-Nom 2V
Voltage Tolerance-Max 4%
Output Voltage Accuracy 2 %

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
