L78M06ABDT

STMicroelectronics
RoHS
/
Package TO-252
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Positive GULL WING BIPOLAR EAR99 voltage regulator linear 125C 500mA 6.5mm 2V
PDF
/
Buying Options
Total Price: USD $0.07
Unit Price: USD $0.073495
≥1 USD $0.073495
≥500 USD $0.054038
≥1000 USD $0.045032
≥2000 USD $0.041316
≥5000 USD $0.038611
≥10000 USD $0.035921
≥15000 USD $0.034745
≥50000 USD $0.034153
Inventory: 1609
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 6.5mm

Technical

Voltage Tolerance-Max 5%
Dropout Voltage1-Nom 2V
Max Input Voltage 35V
Min Input Voltage 35V
Output Voltage 1 6V
Voltage - Output 6V
Accuracy 2 %
Quiescent Current 6mA
Current - Output 500mA
Polarity Positive
Max Output Current 500mA
Output Type Fixed
Number of Outputs 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.25mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Other Regulators
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e3

Physical

Number of Pins 3
Package / Case TO-252
Mount Surface Mount
