L78L24CD-TR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
L78L24 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 1.7V 1.65mm 100mA 0C~125C
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.32824
≥100 USD $0.30624
≥500 USD $0.245168
≥1000 USD $0.227638
≥3000 USD $0.192597
Inventory: 1485
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number L78L24
Pin Count 8
Current - Supply (Max) 6mA
Number of Outputs 1
Voltage - Input (Max) 40V
Output Voltage 24V
Output Type Fixed
Max Output Current 100mA
Output Configuration Positive
Quiescent Current 6.5mA
Accuracy 8 %
Output Voltage 1 24V
Number of Regulators 1
Min Input Voltage 40V
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 5.5mA
PSRR 37dB (120Hz)
Dropout Voltage 1.7V
Dropout Voltage1-Nom 1.7V
Min Output Voltage 24V
Voltage Tolerance-Max 10%
Output Voltage Accuracy 8 %
Dimensions
Height 1.65mm
Length 5mm
Width 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
