L78L10CD13TR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
L78L10 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 1.7V 4.9mm 100mA 0C~125C
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.24795
≥1 USD $0.24795
≥10 USD $0.2033
≥100 USD $0.19665
≥500 USD $0.19095
≥1000 USD $0.1843
Inventory: 53506
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Output Voltage Accuracy 10 %
Input Voltage Absolute-Max 35V
Voltage Tolerance-Max 10%
Dropout Voltage1-Nom 1.7V
Dropout Voltage 1.7V
PSRR 45dB (120Hz)
Current - Quiescent (Iq) 5.5mA
Protection Features Over Current, Over Temperature, Short Circuit
Number of Regulators 1
Output Voltage 1 10V
Quiescent Current 6mA
Current - Output 100mA
Output Configuration Positive
Output Type Fixed
Output Voltage 10V
Voltage - Input (Max) 30V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 8
Base Part Number L78L10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
