L78L09CD13TR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description L78L09 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 1.7V 1.65mm 100mA 0C~125C
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308
≥1 USD $0.308
≥10 USD $0.2508
≥100 USD $0.229152
≥500 USD $0.170632
≥1000 USD $0.154669
Inventory: 362
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status NRND (Last Updated: 2 weeks ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8

Technical

Operating Temperature 0°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number L78L09
Pin Count 8
Number of Outputs 1
Voltage - Input (Max) 30V
Output Voltage 9V
Output Type Fixed
Output Voltage Accuracy 8 %
Voltage Tolerance-Max 10%
Dropout Voltage1-Nom 1.7V
Dropout Voltage 1.7V
PSRR 44dB (120Hz)
Current - Quiescent (Iq) 5.5mA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 30V
Number of Regulators 1
Output Voltage 1 9V
Accuracy 8 %
Quiescent Current 6mA
Output Configuration Positive
Max Output Current 100mA

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 4mm
Length 5mm
Height 1.65mm
