L7809ACD2T

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description L7809 Tube Surface Mount Over Temperature Short Circuit voltage regulator linear 2V 2.54mm 1.5A 0C~125C
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.587732
≥1 USD $1.587732
≥10 USD $1.497866
≥100 USD $1.413076
≥500 USD $1.333096
≥1000 USD $1.257634
Inventory: 1596
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3

Technical

Operating Temperature 0°C~125°C
Packaging Tube
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish TIN LEAD
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number L7809
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Outputs 1
Voltage - Input (Max) 35V
Output Voltage 9V
Output Type Fixed
Max Output Current 1.5A
Output Configuration Positive
Quiescent Current 6mA
Accuracy 2 %
Output Voltage 1 9V
Number of Regulators 1
Min Input Voltage 35V
Protection Features Over Temperature, Short Circuit
Current - Quiescent (Iq) 6mA
Voltage Dropout (Max) 2V @ 1A Typ
PSRR 61dB (120Hz)
Dropout Voltage 2V
Dropout Voltage1-Nom 2V
Voltage Tolerance-Max 4%

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
