L4931ABD50
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Lead Free Positive GULL WING Linear Voltage Regulator IC -40C~125C 250mA 4.9mm 400mV
PDF
/
Buying Options
Total Price: USD $8.3
Unit Price: USD $8.2954
≥1 USD $8.2954
≥10 USD $6.80675
≥100 USD $6.59395
≥500 USD $6.38115
≥1000 USD $6.16835
Inventory: 5160
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number L4931
Pin Count 8
Current - Supply (Max) 6mA
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 20V
Output Voltage 5V
Output Type Fixed
Output Configuration Positive
Current - Output 250mA
Quiescent Current 1mA
Output Voltage 1 5V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature
Voltage Dropout (Max) 0.8V @ 250mA
PSRR 70dB ~ 55dB (120Hz ~ 10kHz)
Dropout Voltage 400mV
Dropout Voltage1-Nom 0.4V
Voltage Tolerance-Max 2%
Input Voltage Absolute-Max 20V
Input Bias Current 600μA
Output Voltage Accuracy 1 %
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
