KF80BDT-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
KF80 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 400mV 2.4mm 500mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3816
≥1 USD $1.3816
≥10 USD $1.232
≥100 USD $1.168992
≥500 USD $0.960344
≥1000 USD $0.897741
≥3000 USD $0.793355
Inventory: 2486
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.25mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number KF80
Pin Count 3
JESD-30 Code R-PSSO-G2
Current - Supply (Max) 12mA
Number of Outputs 1
Voltage - Input (Max) 20V
Output Voltage 8V
Output Type Fixed
Max Output Current 500mA
Output Configuration Positive
Quiescent Current 1.5mA
Accuracy 2 %
Output Voltage 1 8V
Number of Regulators 1
Min Input Voltage -500mV
Protection Features Over Current, Over Temperature
Voltage Dropout (Max) 0.7V @ 500mA
PSRR 72dB ~ 60dB (120Hz ~ 10kHz)
Dropout Voltage 400mV
Dropout Voltage1-Nom 0.4V
Min Output Voltage 8V
Voltage Tolerance-Max 4%
Input Bias Current 700μA
Output Voltage Accuracy 2 %
Dimensions
Height 2.4mm
Length 6.6mm
Width 6.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
