PQ012FZ01ZPH
RoHS
/
Package SC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Positive GULL WING Not Qualified R-PSSO-G5 voltage regulator linear 85C 8W 1A 3.05mm
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.41515
≥1 USD $0.41515
≥10 USD $0.34105
≥100 USD $0.32965
≥500 USD $0.3192
≥1000 USD $0.30875
Inventory: 6467
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5.5mm
Height Seated (Max) 3.05mm
Technical
Max Input Voltage 3.7V
Min Input Voltage 1.7V
Output Voltage 1 1.2V
Voltage - Output 1.2V
Current - Output 1A
Power Dissipation-Max 8W
Polarity Positive
Output Type Fixed
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSSO-G5
Time@Peak Reflow Temperature-Max (s) 10
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Terminal Finish TIN COPPER
Number of Terminations 5
JESD-609 Code e2
Physical
Surface Mount YES
Package / Case SC
