PQ7DV10BJ00H
RoHS
/
Package TO-3P-3, SC-65-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Tube Through Hole Over Current Over Temperature RoHS Compliant voltage regulator linear 500mV 10A 60W -20C~80C
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Voltage - Output (Max) 7V
Dropout Voltage 500mV
Reference Voltage 1.275V
PSRR 55dB (120Hz)
Max Input Voltage 10V
Voltage Dropout (Max) 0.5V @ 10A
Protection Features Over Current, Over Temperature
Min Input Voltage 3V
Number of Regulators 1
Voltage - Output (Min/Fixed) 1.5V
Control Features Enable
Current - Output 10A
Output Configuration Positive
Output Type Adjustable
Output Voltage 7V
Voltage - Input (Max) 10V
Number of Outputs 1
Max Power Dissipation 60W
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 1999
Packaging Tube
Operating Temperature -20°C~80°C
Physical
Supplier Device Package TO-3P
Package / Case TO-3P-3, SC-65-3
Mounting Type Through Hole
Mount Through Hole
