BD15GA5WEFJ-E2
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
BD15 Tape & Reel (TR) Surface Mount Over Current Over Temperature Soft Start voltage regulator linear 600mV 4.9mm 500mA 2.11W
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.275792
≥1 USD $0.275792
≥10 USD $0.256775
≥100 USD $0.247262
≥500 USD $0.237758
Inventory: 1335
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Dropout Voltage 600mV
Voltage Dropout (Max) 0.9V @ 500mA
Current - Quiescent (Iq) 0.6mA
Protection Features Over Current, Over Temperature, Soft Start
Min Input Voltage 4.5V
Number of Regulators 1
Output Voltage 1 9V
Control Features Enable
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Output Voltage 1.5V
Voltage - Input (Max) 14V
Current - Supply (Max) 900μA
Base Part Number BD15
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 2.11W
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
