BD00HA5WEFJ-E2
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
BD00 Tape & Reel (TR) Surface Mount Over Current Over Temperature Soft Start voltage regulator linear 600mV 500mA 2.11W -25C~85C
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
≥10 USD $0.68024
≥100 USD $0.639232
≥500 USD $0.521664
≥1000 USD $0.484563
≥3000 USD $0.412403
Inventory: 1199
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Technical
Voltage - Output (Max) 7V
Min Output Voltage 1.5V
Dropout Voltage1-Nom 0.6V
Dropout Voltage 600mV
Voltage Dropout (Max) 0.9V @ 500mA
Current - Quiescent (Iq) 0.6mA
Protection Features Over Current, Over Temperature, Soft Start
Min Input Voltage 4.5V
Number of Regulators 1
Max Output Voltage 7V
Control Features Enable
Output Configuration Positive
Max Output Current 500mA
Output Type Adjustable
Output Voltage 7V
Voltage - Input (Max) 8V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 900μA
Pin Count 8
Base Part Number BD00
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 2.11W
Packing Method TAPE AND REEL
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Tin
Supply Chain
Factory Lead Time 9 Weeks
