BA7807FP-E2
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
BA78 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 2V 6.5mm 1A 10W
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.81576
≥100 USD $0.774048
≥500 USD $0.6358
≥1000 USD $0.594282
≥3000 USD $0.525184
Inventory: 1167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Subcategory Other Regulators
Packing Method TAPE AND REEL
Max Power Dissipation 10W
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number BA78
Pin Count 4
JESD-30 Code R-PSSO-G2
Current - Supply (Max) 800μA
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 22V
Output Voltage 7V
Output Type Fixed
Max Output Current 1A
Output Configuration Positive
Accuracy 4 %
Output Voltage 1 7V
Number of Regulators 1
Min Input Voltage 9.5V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 8mA
Voltage Dropout (Max) 2V @ 1A Typ
PSRR 69dB (120Hz)
Dropout Voltage 2V
Dropout Voltage1-Nom 2V
