LP2985IM5-5.3
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead GULL WING 8542.39.00.01 FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR voltage regulator linear 125C 0.15A 2.92mm 7mV
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 2001
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Width 1.6mm
Length 2.92mm
Height Seated (Max) 1.22mm
Technical
Operating Temperature TJ-Min -40°C
Operating Temperature TJ-Max 125°C
Output Current1-Max 0.15A
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Dropout Voltage 7mV
Input Voltage (Max) 16V
Input Voltage (Min) 6.3V
Output Voltage 1 5.3V
Voltage - Output 5.3V
JESD-30 Code R-PDSO-G5
Pin Count 5
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.953mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8542.39.00.01
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e0
Packaging Cut Tape
Physical
Surface Mount YES
Package / Case SOT-23
