MAX1589ETT180+T
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Tape & Reel (TR) Surface Mount Over Temperature Short Circuit ROHS3Compliant voltage regulator linear 1.8V 3mm 500mA -40C~85C TA
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.881
≥1 USD $1.881
≥10 USD $1.5428
≥100 USD $1.4953
≥500 USD $1.44685
≥1000 USD $1.3984
Inventory: 1121
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
PSRR 70dB (1kHz)
Voltage Dropout (Max) 0.35V @ 500mA
Current - Quiescent (Iq) 140μA
Protection Features Over Temperature, Short Circuit
Number of Regulators 1
Voltage - Output (Min/Fixed) 1.8V
Output Voltage 1 1.8V
Control Features Enable, Reset
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 3.6V
JESD-30 Code S-XDSO-N6
Pin Count 6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.95mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology BICMOS
Terminal Finish MATTE TIN
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount
