NCV8606MN25T2G

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 6-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description NCV8606 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 200mV 850mum 500mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.641388
≥1 USD $0.641388
≥10 USD $0.616713
Inventory: 1200
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 3.3mm
Length 3mm
Height 850μm

Technical

Min Current Limit 675mA
Voltage Tolerance-Max 2%
Min Output Voltage 2.5V
Dropout Voltage1-Nom 0.2V
Dropout Voltage 200mV
Voltage Dropout (Max) 0.25V @ 500mA
Current - Quiescent (Iq) 180μA
Protection Features Over Current, Over Temperature
Min Input Voltage 1.5V
Number of Regulators 1
Output Voltage 1 2.5V
Accuracy 2 %
Control Features Enable
Output Configuration Positive
Max Output Current 500mA
Output Type Fixed
Output Voltage 2.5V
Voltage - Input (Max) 6V
Number of Outputs 1
Pin Count 6
Base Part Number NCV8606
Terminal Pitch 0.95mm
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Number of Pins 6
Package / Case 6-VDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
