NCP566ST18T3G
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
NCP566 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 900mV 1.65mm 1.5A -40C~125C
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.137638
≥1 USD $0.137638
≥10 USD $0.129849
≥100 USD $0.12249
≥500 USD $0.115561
≥1000 USD $0.109023
Inventory: 1448
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.7mm
Length 6.7mm
Height 1.65mm
Technical
Output Voltage Accuracy 3 %
Nominal Output Voltage 1.8V
Min Current Limit 1.6A
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 0.9V
Dropout Voltage 900mV
Reference Voltage 900mV
PSRR 85dB ~ 75db (120Hz ~ 1kHz)
Halogen Free Halogen Free
Voltage Dropout (Max) 1.3V @ 1.5A
Current - Quiescent (Iq) 3mA
Protection Features Over Current, Over Temperature
Min Input Voltage 3.4V
Number of Regulators 1
Output Voltage 1 1.8V
Max Output Voltage 1.8V
Accuracy 3 %
Output Configuration Positive
Min Supply Voltage 3.4V
Max Supply Voltage 9V
Max Output Current 1.5A
Output Type Fixed
Output Voltage 1.8V
Number of Outputs 1
Pin Count 4
Base Part Number NCP566
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 2.3mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 4
Package / Case TO-261-4, TO-261AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 2 Weeks
