NCP114AMX350TCG
RoHS
RoHS compliant
RoHS compliantPackage 4-UDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Tape & Reel (TR) Surface Mount Over Current Over Temperature ROHS3Compliant voltage regulator linear 6V 0.6mm 300mA -40C~85C TA
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.2992
≥100 USD $0.261888
≥500 USD $0.149688
≥1000 USD $0.140307
≥3000 USD $0.112253
Inventory: 1184
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-UDFN Exposed Pad
Number of Pins 4
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2014
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Subcategory Other Regulators
Technology CMOS
Terminal Position DUAL
Number of Functions 1
Terminal Pitch 0.65mm
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 3.5V
Output Type Fixed
Max Output Current 300mA
Output Configuration Positive
Quiescent Current 50μA
Control Features Enable
Accuracy 1 %
Output Voltage 1 3.5V
Number of Regulators 1
Min Input Voltage 1.7V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 95μA
PSRR 75dB (1kHz)
Min Current Limit 300mA
Input Voltage Absolute-Max 6V
Dimensions
Height Seated (Max) 0.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
