KA337
RoHS
/
Package TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
KA337 Bulk Through Hole Over Temperature Short Circuit voltage regulator linear 3V 2.54mm 1.5A 0C~125C
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.22833
≥1 USD $0.22833
≥10 USD $0.215406
≥100 USD $0.203211
≥500 USD $0.191708
≥1000 USD $0.180862
Inventory: 1648
Minimum: 1
-
+
Technical Details
Technical
Voltage - Output (Max) -37V
Dropout Voltage1-Nom 3V
PSRR 60dB (120Hz)
Protection Features Over Temperature, Short Circuit
Number of Regulators 1
Voltage - Output (Min/Fixed) -1.2V
Current - Output 1.5A
Output Configuration Negative
Output Type Adjustable
Voltage - Input (Max) -40V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSFM-T3
Base Part Number KA337
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology BIPOLAR
Packing Method RAIL
Subcategory Other Regulators
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2013
Packaging Bulk
Operating Temperature 0°C~125°C
Physical
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
