CAT6221-JFTD-GT3

ON Semiconductor
RoHS
/
Package TSOT
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Lead Free Positive GULL WING CMOS voltage regulator linear 125C 300mA 1mm 350mV
PDF
/
Inventory: 8256
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status LAST SHIPMENTS (Last Updated: 2 weeks ago)

Physical

Mount Surface Mount
Package / Case TSOT
Number of Pins 6

Technical

JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 0.95mm
Pin Count 6
Number of Outputs 2
Output Type Fixed
Polarity Positive
Current - Output 300mA
Accuracy 1 %
Voltage - Output 1.5V
Output Voltage 1 2.5V
Min Input Voltage 0V
Max Input Voltage 6.5V
Halogen Free Halogen Free
Dropout Voltage 350mV
Dropout Voltage1-Nom 0.21V
Voltage Tolerance-Max 2%
Load Regulation-Max(%) 0.05%
Output Voltage 2 1.5V

Dimensions

Height Seated (Max) 1mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
