LM2575M-12
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead BUCK GULL WING Not Qualified voltage regulator linear 125C 3.2A 63kHz 2.65mm
PDF
/
Buying Options
Total Price: USD $50.66
Unit Price: USD $50.65685
≥1 USD $50.65685
≥10 USD $41.5644
≥100 USD $40.26575
≥500 USD $38.9671
≥1000 USD $37.66845
Inventory: 5176
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Switching Frequency-Max 63kHz
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 40V
Output Current-Max 3.2A
Control Mode VOLTAGE-MODE
Min Input Voltage 4V
Voltage - Output 12V
Analog IC - Other Type SWITCHING REGULATOR
Temperature Grade AUTOMOTIVE
Input Voltage-Nom 12V
Output Type Fixed
Qualification Status Not Qualified
Number of Outputs 1
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 24
Published 2013
Physical
Number of Pins 24
Mount Surface Mount
