SG7824IG
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
BIPOLAR 8542.39.00.01 FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR SINGLE voltage regulator linear 150C 1.5A 25V
PDF
/
Inventory: 7540
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 3 weeks ago)
Physical
Mount Through Hole
Technical
Packaging Bulk
Number of Terminations 3
ECCN Code EAR99
HTS Code 8542.39.00.01
Technology BIPOLAR
Terminal Position SINGLE
Number of Functions 1
Pin Count 3
JESD-30 Code R-XSFM-T3
Output Voltage 1 24V
Input Voltage (Min) 27V
Input Voltage (Max) 38V
Output Voltage1-Max 25V
Output Voltage1-Min 23V
Regulator Type FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR
Output Current1-Max 1.5A
Operating Temperature TJ-Max 150°C
Operating Temperature TJ-Min -55°C
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Alternative Model
