SG7805AR
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Positive Not Qualified BIPOLAR e0 voltage regulator linear 125C 3.3A 2V
PDF
/
Inventory: 4905
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 month ago)
Physical
Mount Through Hole
Number of Pins 3
Technical
Packaging Bulk
JESD-609 Code e0
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory Other Regulators
Technology BIPOLAR
Pin Count 2
Number of Outputs 1
Qualification Status Not Qualified
Output Type Fixed
Max Output Current 3.3A
Polarity Positive
Quiescent Current 6mA
Accuracy 1.5 %
Voltage - Output 5V
Output Voltage 1 5V
Max Input Voltage 35V
Dropout Voltage1-Nom 2V
Voltage Tolerance-Max 3%
Load Regulation-Max(%) 0.05%
Line Regulation-Max (%/V) 0.025%
Compliance
Radiation Hardening Yes
RoHS Status RoHS Compliant
