SG140-06L
RoHS
/
Package CLCC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Positive BIPOLAR EAR99 Fixed voltage regulator linear 125C 6mA 2V
PDF
/
Inventory: 6541
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 weeks ago)
Physical
Mount Surface Mount
Package / Case CLCC
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Number of Terminations 20
ECCN Code EAR99
Terminal Finish TIN LEAD
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position QUAD
Number of Functions 1
Pin Count 20
JESD-30 Code S-CQCC-N20
Number of Outputs 1
Output Type Fixed
Polarity Positive
Quiescent Current 6mA
Accuracy 2 %
Voltage - Output 6V
Output Voltage 1 6V
Max Input Voltage 35V
Dropout Voltage1-Nom 2V
Voltage Tolerance-Max 5%
Load Regulation-Max(%) 0.06%
Line Regulation-Max (%/V) 0.06%
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
