SG120-12R
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Negative PIN/PEG BIPOLAR EAR99 voltage regulator linear 125C 1.5A 1.1V
PDF
/
Inventory: 7921
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 month ago)
Physical
Mount Through Hole
Number of Pins 3
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position BOTTOM
Terminal Form PIN/PEG
Number of Functions 1
Pin Count 2
JESD-30 Code O-MBFM-P2
Number of Outputs 1
Output Type Fixed
Max Output Current 1.5A
Polarity Negative
Quiescent Current 4mA
Voltage - Output -12V
Output Voltage 1 12V
Max Input Voltage -35V
Dropout Voltage1-Nom 1.1V
Voltage Tolerance-Max 4%
Load Regulation-Max(%) 0.08%
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
