TC1302B-IPVMF

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description TC1302B Tube Surface Mount Over Current Over Temperature voltage regulator linear 0.104V 3mm 300mA 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.596593
≥1 USD $0.596593
≥10 USD $0.562823
≥100 USD $0.530964
≥500 USD $0.500908
≥1000 USD $0.472551
Inventory: 1503
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 3mm
Length 3mm
Height Seated (Max) 1mm

Technical

Output Voltage 2 1.8V
Output Voltage Accuracy 0.5 %
Input Bias Current 58μA
Input Voltage Absolute-Max 6.5V
Dropout Voltage1-Nom 0.104V
PSRR 58dB (100Hz)
Voltage Dropout (Max) - -
Current - Quiescent (Iq) 180μA
Protection Features Over Current, Over Temperature
Min Input Voltage 2.7V
Number of Regulators 2
Voltage - Output (Min/Fixed) 2.5V 1.8V
Output Voltage 1 2.5V
Accuracy 0.5 %
Control Features Enable
Quiescent Current 114μA
Current - Output 300mA 150mA
Output Configuration Positive
Output Type Fixed
Output Voltage 1.8V
Voltage - Input (Max) 6V
Number of Outputs 2
Pin Count 8
Base Part Number TC1302B
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tube
Operating Temperature -40°C~125°C

Physical

Number of Pins 8
Package / Case 8-VDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
