SG7805AK-DESC

Microchip Technology
RoHS
RoHS RoHS compliant
Package TO-204AA, TO-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description SG7805 Tray Through Hole Over Current Over Temperature voltage regulator linear 2V 1.5A -55C~125C
PDF
/
Inventory: 5187
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Technical

Output Voltage Accuracy 1.5 %
Min Current Limit 1.5A
Dropout Voltage1-Nom 2V
Dropout Voltage 2V
PSRR 68dB (120Hz)
Voltage Dropout (Max) 2.5V @ 1A
Current - Quiescent (Iq) 7mA
Protection Features Over Current, Over Temperature
Number of Regulators 1
Output Voltage 1 5V
Accuracy 1.5 %
Quiescent Current 6mA
Output Configuration Positive
Max Output Current 1.5A
Output Type Fixed
Output Voltage 5V
Voltage - Input (Max) 35V
Number of Outputs 1
JESD-30 Code O-MBFM-P2
Pin Count 2
Base Part Number SG7805
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position BOTTOM
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Series Military, MIL-STD-883
Published 2009
Packaging Tray
Operating Temperature -55°C~125°C

Physical

Number of Pins 3
Package / Case TO-204AA, TO-3
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 10 Weeks

Alternative Model
