MIC69302WR image
Favorite
MIC69302WR image
Favorite
RoHS
RoHS RoHS compliant
Package SPak-5 (5 leads + Tab)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description MIC69302 Tube Surface Mount Over Current Over Temperature voltage regulator linear 275mV 2.03mm 3A -40C~125C
PDF
/
Buying Options
Total Price: USD $3.16
Unit Price: USD $3.1592
≥1 USD $3.1592
≥10 USD $2.6488
≥100 USD $2.3848
Inventory: 74
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 14 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case SPak-5 (5 leads + Tab)
Number of Pins 5
Supplier Device Package S-PAK-5

Technical

Operating Temperature -40°C~125°C
Packaging Tube
Published 2011
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Base Part Number MIC69302
Current - Supply (Max) 75mA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 5V
Output Type Adjustable
Max Output Current 3A
Output Configuration Positive
Current - Output 3A
Control Features Enable
Accuracy 2 %
Max Output Voltage 5V
Voltage - Output (Min/Fixed) 0.5V
Number of Regulators 1
Min Input Voltage 1.65V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 5mA
Voltage Dropout (Max) 0.5V @ 3A
Max Input Voltage 5.5V
Dropout Voltage 275mV
Min Output Voltage 1.2V
Voltage - Output (Max) 5V
Min Current Limit 3.3A

Dimensions

Height 2.03mm
Length 9.52mm
Width 8.13mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
