MIC5366-2.9YMT-TZ
RoHS
RoHS compliant
RoHS compliantPackage 4-UDFN Exposed Pad, 4-TMLF?
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MIC5366 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 155mV 0.6mm 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 79612
Minimum: 1
-
+
Technical Details
Technical
Current - Output 150mA
Control Features Enable
Output Voltage 1 2.9V
Input Voltage (Min) 3.9V
Number of Regulators 1
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 39μA
Voltage Dropout (Max) 0.31V @ 150mA
PSRR 80dB ~ 65dB (1kHz ~ 10kHz)
Dropout Voltage 155mV
Dropout Voltage1-Nom 0.155V
Voltage Tolerance-Max 3%
Min Current Limit 200mA
Input Voltage Absolute-Max 6V
Output Configuration Positive
Output Type Fixed
Output Voltage 2.9V
Voltage - Input (Max) 5.5V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code S-PDSO-N4
Base Part Number MIC5366
Terminal Pitch 0.625mm
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height Seated (Max) 0.6mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Package / Case 4-UDFN Exposed Pad, 4-TMLF?
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
