MIC5335-PGYMT-TR
RoHS
RoHS compliant
RoHS compliantPackage 6-UFDFN Exposed Pad, 6-TMLF?
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MIC5335 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 75mV 0.5mm 300mA 300mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.323
≥1 USD $0.323
≥10 USD $0.26505
≥100 USD $0.2565
≥500 USD $0.24795
≥1000 USD $0.24035
Inventory: 285
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-UFDFN Exposed Pad, 6-TMLF?
Number of Pins 6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Packing Method TR
Technology CMOS
Terminal Position DUAL
Terminal Form NO LEAD
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number MIC5335
Current - Supply (Max) 220μA
Number of Outputs 2
Voltage - Input (Max) 5.5V
Output Voltage 1.8V
Output Type Fixed
Output Configuration Positive
Current - Output 300mA 300mA
Control Features Enable
Output Voltage 1 3V
Input Voltage (Min) 4V
Voltage - Output (Min/Fixed) 1.8V 3V
Number of Regulators 2
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 125μA
Voltage Dropout (Max) 0.2V @ 300mA 0.2V @ 300mA
PSRR 65dB ~ 45dB (1kHz ~ 20kHz)
Dropout Voltage 75mV
Dropout Voltage1-Nom 0.075V
Voltage Tolerance-Max 3%
Min Current Limit 340mA
Input Voltage Absolute-Max 6V
Output Voltage 2 1.8V
Compliance
RoHS Status ROHS3 Compliant
