MIC5330-PKYML-TR

Microchip Technology
RoHS
RoHS RoHS compliant
Package 8-VFDFN Exposed Pad, 8-MLF?
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description MIC5330 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 75mV 300mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.1
Unit Price: USD $1.096272
≥1 USD $1.096272
≥200 USD $0.424067
≥500 USD $0.409625
≥1000 USD $0.401747
Inventory: 1600
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VFDFN Exposed Pad, 8-MLF?
Number of Pins 8
Supplier Device Package 8-MLF? (2x2)

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Base Part Number MIC5330
Current - Supply (Max) 200μA
Number of Outputs 2
Voltage - Input (Max) 5.5V
Output Voltage 2.6V
Output Type Fixed
Max Output Current 300mA
Output Configuration Positive
Current - Output 300mA 300mA
Control Features Enable
Voltage - Output (Min/Fixed) 2.6V 3V
Number of Regulators 2
Min Input Voltage 2.3V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 120μA
Voltage Dropout (Max) 0.2V @ 300mA 0.2V @ 300mA
Max Input Voltage 5.5V
PSRR 70dB ~ 65dB (1kHz ~ 20kHz)
Dropout Voltage 75mV
Min Output Voltage 2.6V
Min Current Limit 350mA

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
