MIC5301-1.5YD5-TR

Microchip Technology
RoHS
RoHS RoHS compliant
Package SOT-23-5 Thin, TSOT-23-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Active Positive Fixed Enable Linear Voltage Regulator IC -40C~125C 150mA 40mV
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.6248
≥100 USD $0.594
Inventory: 864
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-5 Thin, TSOT-23-5
Supplier Device Package TSOT-23-5

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Base Part Number MIC5301
Voltage - Input (Max) 5.5V
Output Voltage 1.5V
Min Current Limit 275mA
Dropout Voltage 40mV
PSRR 75dB ~ 50dB (1kHz ~ 20kHz)
Voltage Dropout (Max) 0.1V @ 150mA
Current - Quiescent (Iq) 120μA
Protection Features Over Current, Over Temperature
Number of Regulators 1
Voltage - Output (Min/Fixed) 1.5V
Control Features Enable
Current - Output 150mA
Output Configuration Positive
Output Type Fixed

Compliance

RoHS Status ROHS3 Compliant
