MIC5213-5.0YC5-TR

Microchip Technology
RoHS
RoHS RoHS compliant
Package 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description MIC5213 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 280mV 1mm 80mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.4312
≥100 USD $0.396
Inventory: 1186
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 7 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-TSSOP, SC-70-5, SOT-353
Number of Pins 5
Supplier Device Package SC-70-5

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series Teeny?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Base Part Number MIC5213
Current - Supply (Max) 3mA
Number of Outputs 1
Voltage - Input (Max) 16V
Output Voltage 5V
Output Type Fixed
Max Output Current 80mA
Polarity Positive
Output Configuration Positive
Current - Output 80mA
Quiescent Current 10μA
Control Features Enable
Accuracy 4 %
Voltage - Output (Min/Fixed) 5V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 750μA
Voltage Dropout (Max) 0.6V @ 80mA
Max Input Voltage 16V
Dropout Voltage 280mV
Min Output Voltage 5V
Nominal Output Voltage 5V
Output Voltage Accuracy 3 %

Dimensions

Height 1mm
Length 2.2mm
Width 1.35mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
