MIC5209-4.2YS
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MIC5209 Tube Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 350mV 6.5mm 500mA 256mW
PDF
/
Buying Options
Total Price: USD $1.42
Unit Price: USD $1.4168
≥1 USD $1.4168
≥10 USD $1.1792
≥100 USD $1.0736
Inventory: 57
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Number of Pins 4
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish MATTE TIN
Max Power Dissipation 256mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.3mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MIC5209
Current - Supply (Max) 25mA
Qualification Status Not Qualified
Voltage - Input (Max) 16V
Output Voltage 4.2V
Output Type Fixed
Output Configuration Positive
Current - Output 500mA
Output Voltage 1 4.2V
Number of Regulators 1
Min Input Voltage 2.5V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 170μA
Voltage Dropout (Max) 0.6V @ 500mA
PSRR 75dB (120Hz)
Dropout Voltage 350mV
Power Supply Rejection Ratio (PSRR) 75dB
Dimensions
Length 6.5mm
Width 3.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
