MIC5209-3.6BU TR
RoHS
/
Package TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Positive Fixed Enable Linear Voltage Regulator IC -40C~125C 500mA 16V
PDF
/
Inventory: 9355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
PSRR 75dB (120Hz)
Voltage Dropout (Max) 0.6V @ 500mA
Current - Quiescent (Iq) 170μA
Protection Features Over Current, Over Temperature, Reverse Polarity
Number of Regulators 1
Voltage - Output (Min/Fixed) 3.6V
Control Features Enable
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 16V
Current - Supply (Max) 25mA
Base Part Number MIC5209
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Supplier Device Package TO-263-5
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Mounting Type Surface Mount
