MIC29371-12WT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MIC29371-12 Tube Through Hole Over Current Over Temperature voltage regulator linear 370mV 750mA -40C~125C
PDF
/
Buying Options
Total Price: USD $5.28
Unit Price: USD $5.28341
≥1 USD $5.28341
≥10 USD $4.984348
≥100 USD $4.70222
≥500 USD $4.436059
≥1000 USD $4.18496
Inventory: 1140
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Dropout Voltage 370mV
Voltage Dropout (Max) 0.75V @ 750mA
Current - Quiescent (Iq) 300μA
Protection Features Over Current, Over Temperature
Number of Regulators 1
Input Voltage (Min) 2V
Output Voltage 1 12V
Control Features Enable
Current - Output 750mA
Output Configuration Positive
Output Type Fixed
Output Voltage 12V
Voltage - Input (Max) 26V
Qualification Status Not Qualified
Current - Supply (Max) 16mA
Base Part Number MIC29371-12
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Number of Functions 1
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Position SINGLE
Technology BIPOLAR
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2006
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case TO-220-5
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
