MCP1827ST-1802E/EB
RoHS
RoHS compliant
RoHS compliantPackage TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1827S Tape & Reel (TR) Surface Mount Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 330mV 5.08mm 1.5A -40C~125C
PDF
/
Buying Options
Total Price: USD $8.97
Unit Price: USD $8.974911
≥1 USD $8.974911
≥10 USD $8.466903
≥100 USD $7.987648
≥500 USD $7.53551
≥1000 USD $7.10898
Inventory: 1589
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 5.08mm
Technical
Output Voltage Accuracy 2 %
Input Bias Current 120μA
Input Voltage Absolute-Max 6.5V
Voltage Tolerance-Max 2.5%
Dropout Voltage1-Nom 0.33V
Dropout Voltage 330mV
PSRR 60dB (100Hz)
Voltage Dropout (Max) 0.6V @ 1.5A
Current - Quiescent (Iq) 220μA
Protection Features Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Min Input Voltage 2.3V
Number of Regulators 1
Output Voltage 1 1.8V
Accuracy 2 %
Quiescent Current 120μA
Output Configuration Positive
Max Output Current 1.5A
Output Type Fixed
Output Voltage 1.8V
Voltage - Input (Max) 6V
Number of Outputs 1
Pin Count 3
Base Part Number MCP1827S
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
Alternative Model
