MCP1827-1802E/AT
RoHS
RoHS compliant
RoHS compliantPackage TO-220-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1827 Tube Through Hole Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 330mV 16.51mm 1.5A -40C~125C
PDF
/
Buying Options
Total Price: USD $2.58
Unit Price: USD $2.57591
≥1 USD $2.57591
≥10 USD $2.448559
≥30 USD $2.37241
Inventory: 25
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-5
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Technology CMOS
Terminal Position SINGLE
Number of Functions 1
Base Part Number MCP1827
Pin Count 3
Number of Outputs 1
Voltage - Input (Max) 6V
Output Voltage 1.8V
Output Type Fixed
Max Output Current 1.5A
Output Configuration Positive
Quiescent Current 220μA
Control Features Enable, Power Good
Accuracy 2 %
Output Voltage 1 1.8V
Number of Regulators 1
Min Input Voltage 2.3V
Protection Features Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Voltage Dropout (Max) 0.6V @ 1.5A
PSRR 60dB (100Hz)
Dropout Voltage 330mV
Dropout Voltage1-Nom 0.33V
Nominal Output Voltage 1.8V
Input Bias Current 120μA
Output Voltage Accuracy 2 %
Dimensions
Height 16.51mm
Length 10.67mm
Width 4.826mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
