MCP1825T-2502E/ET
RoHS
RoHS compliant
RoHS compliantPackage TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1825 Tape & Reel (TR) Surface Mount Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 210mV 500mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.029314
≥1 USD $1.029314
≥200 USD $0.399122
≥750 USD $0.38468
≥1500 USD $0.378115
Inventory: 1604
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Input Bias Current 120μA
Dropout Voltage1-Nom 0.21V
Dropout Voltage 210mV
PSRR 60dB (100Hz)
Voltage Dropout (Max) 0.35V @ 500mA
Current - Quiescent (Iq) 220μA
Protection Features Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Min Input Voltage 2.1V
Number of Regulators 1
Output Voltage 1 2.5V
Control Features Enable, Power Good
Quiescent Current 220μA
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Output Voltage 2.5V
Voltage - Input (Max) 6V
Number of Outputs 1
Pin Count 5
Base Part Number MCP1825
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position SINGLE
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
