MCP1825ST-3302E/EB
RoHS
RoHS compliant
RoHS compliantPackage TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1825S Tape & Reel (TR) Surface Mount Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 210mV 5.08mm 500mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.1968
≥1 USD $1.1968
≥10 USD $0.9944
≥100 USD $0.9064
Inventory: 765
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Number of Pins 3
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP1825S
Pin Count 3
Number of Outputs 1
Voltage - Input (Max) 6V
Output Voltage 3.3V
Output Type Fixed
Output Configuration Positive
Current - Output 500mA
Quiescent Current 220μA
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage 2.1V
Protection Features Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 220μA
Voltage Dropout (Max) 0.35V @ 500mA
PSRR 60dB (100Hz)
Dropout Voltage 210mV
Dropout Voltage1-Nom 0.21V
Voltage Tolerance-Max 2.5%
Input Voltage Absolute-Max 6.5V
Input Bias Current 120μA
Dimensions
Height Seated (Max) 5.08mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
