MCP1812AT-018/LT
RoHS
/
Package 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Tape & Reel (TR) Surface Mount Over Current Enable voltage regulator linear 0.4V 2mm 300mA -40C~85C TJ
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.695272
≥1 USD $0.695272
≥10 USD $0.655907
≥100 USD $0.618788
≥500 USD $0.583759
≥1000 USD $0.55072
Inventory: 1101
Minimum: 1
-
+
Technical Details
Dimensions
Length 2mm
Technical
Input Voltage Absolute-Max 6V
Voltage Tolerance-Max 4%
Dropout Voltage1-Nom 0.4V
PSRR 50dB (1kHz)
Voltage Dropout (Max) 0.6V @ 300mA
Current - Quiescent (Iq) 0.5μA
Protection Features Over Current
Number of Regulators 1
Voltage - Output (Min/Fixed) 1.8V
Input Voltage (Min) 2.4V
Output Voltage 1 1.8V
Control Features Enable
Current - Output 300mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 5.5V
Number of Outputs 1
Current - Supply (Max) 220μA
JESD-30 Code R-PDSO-G5
Reach Compliance Code compliant
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TR
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TJ
Physical
Surface Mount YES
Package / Case 5-TSSOP, SC-70-5, SOT-353
Mounting Type Surface Mount
